Material type
Metal
Material name
Aluminum 7075-T6 | 3.4365 | 76528 | AlZn5,5MgCu
Alternative names
AlZn5,5MgCu, 3.4365
Process compatibility
CNC machining
This grade of aluminum is also know as aircraft or aerospace aluminum due its most common application. The dominant element of 7075 alloys is zinc. Its high strength makes is stand out from the other aluminium alloys and be comparable to the strength of many steels. Even though it has convinent combination of properties for many applications, 7075-T6 compared to other aluminium alloys has lower corrosion resistance, but very good machinability
Mechanical properties
Ultimate tensile strength
520-560 MPa
Yield strength
460-470 MPa
Young's modulus
(modulus of elasticity)
(modulus of elasticity)
69 - 76 GPa
Elongation at break
6-9 %
Physical properties
Corrosion resistance
Moderate
Magnetism
Non-magnetic
Weldability
Poor
Thermal properties
Maximum service temperature
100 °C
Thermal expansion coefficent
22,9 - 24,1 10^-6/ºC
Thermal conductivity
131 - 137 W/(m⋅°C)
Electrical properties
Electrical resistivity
5,2 μΩ*cm
Post treatments
Post-Processing
Annealing & Cold working
Anodizing compatibility
Not recommended - due to the high amount of zinc that the material contains, dark spots or corroded marks may be observed
Common applications
Aircraft and aerospace
Marine
Transportation
